- Specification -
| Parameter | 6CH | 10 CH | 12CH | other | |||||||||
Channel Wavelength(nm) | 1270~1610 | ||||||||||||
Center wavelength Accuracy(nm) | ±0.5 | ||||||||||||
Channel Spacing(nm) | 20 | ||||||||||||
Channel Passband(@-0.5dB bandwidth(nm) | >13 | ||||||||||||
Insertion Loss(dB) | ≤2.1 | ≤3.2 | ≤3.8 | / | |||||||||
Channel Uniformity(dB) | ≤1.0 | ||||||||||||
Channel Ripple(dB) | 0.3 | ||||||||||||
Isolation(dB) | Adjacent | >30 | |||||||||||
Non-adjacent | >40 | ||||||||||||
Inertion Loss Temperature Sensitivity(dB/℃) | <0.005 | ||||||||||||
Wavelength Temperature Shifting(nm/℃) | <0.002 | ||||||||||||
Polarization Dependent Loss(dB) | <0.1 | ||||||||||||
Polarization Mode Dispersion(PS) | <0.1 | ||||||||||||
Directivity(dB) | >50 | ||||||||||||
Return Loss（dB） | >45 | ||||||||||||
Maximum Power Handling(mW) | 300 | ||||||||||||
Opterating Temperature(℃) | -5~+75 | ||||||||||||
Storage Temperature(℃) | -40~85 | ||||||||||||
Package dimension(mm) | 1.L100 x W80 x H10(2 CH～8CH) 2.L140xW100xH15(9 CH～18CH) | ||||||||||||
Above specification are for device without connector.
