8 RJ45 EPON-ONU

Model NO.: XYT-8RJ45- EPON-ONU

Quantity:

Product Description

size of product:

Attribute	8-port EPON-ONU
Port	8 cells were fixed at 10/100/1000BASE-T
Port	1 fixed PON port
System capacity	Maximum 1:64 optical ratio
PON port	Up and down symmetric 1Gbps transmission rate
	High sensitivity optical receiver:, not less than-30dBm
	Security: The ONU authentication mechanism
	Network coverage radius: 30 km
Standards to follow	IEEE802.3ah
	IEEE 802.1D, Spanning Tree
	IEEE 802.1Q, VLAN
	IEEE 802.1w, RSTP
	IEEE 802.3ad Physical Link Static/Dynamic Aggregation (LACP)
	Ethernet–II, Ethernet-SNAP
	IEEE 802.3ad VLAN Stacking(QinQ)
Quality of service	Back-pressure flow control (semi-duplex)
	IEEE 802.3x flow control (full-duplex)
	IEEE p802.1p, CoS
	WRR, SP and FIFO queue scheduling algorithm
	Support for 802.1P/DSCP priority Mark/Remark s
	Based on the up and downside speed limit functions for each ONU
	Support for DBA and SLA functions
VLAN	Port-based VLAN
	IEEE802.1Q VLAN relay
	QinQ, and supports flexible QinQ
Group broadcast	IGMP v1/v2/v3
	IGMP Snooping
	multicast VLAN, controlled multicast function
Reliability	Single-direction link detection protocol to prevent the survival tree loop
	Expansion slot EPON optical module hot plug out
	EAPS Fast Loop protection function
	EPON optical road protection
Network security	Limit the maximum number of users per port
	Port isolation
	News storm control
	The control function of ACL access based on data flow
	The PON port transmits data encryption
Configuration management	CLI,Web,SNMP,TELNET,cluster.
	The RMON v1,1,2,3,9group
	SSHv1/v2
	Software upgrades and bootrom upgrades are available through TFTP and FTP
	Local or server syslog records the system logs
	The Chinese and English command prompt
	Network testing tools such as ping,trace route
	Debug the output debug
Physical dimensions	17712627
Physical dimensions	Installation: Desktop type/wall mount
Weight	<0.5kg
Environmental requirements	Working environment: -30℃~55℃; 10%~90% without condensation
Environmental requirements	Storage environment: -40℃ ~80℃; 5%~95% condensation-free
Power supply	Input voltage: AC100~240V, with an input frequency of 47~63Hz
Power supply	Input current:1A/230V, power consumption:12W
