4 RJ45 EPON-ONU

Model NO.: XYT-4PON-EPON-ONU

Quantity:

Product Description

size of product:

Attribute	4-portEPON-ONU
User measurement interface	Four fixed 10/100/1000M BASE-T adaptive RJ45 interfaces
PON port	Up and down symmetric 1Gbps transmission rate
	Network coverage radius: 20 km
	Optical interface type: SC/PC
	High sensitivity optical receiver:, not less than-30dBm
	Optical power: 2-7dBm
	Security: The ONU authentication mechanism
Standards to follow	IEEE 802.3ah
	Industry Standards of Communications (YD/T 1475-2006)
	IEEE 802.1D, Spanning Tree
	IEEE 802.1Q, VLAN
	IEEE 802.1w, RSTP
	Ethernet–II, Ethernet-SNAP
VLAN	Port-based VLAN
VLAN	IEEE 802.1Q VLAN
Quality of service	Back-pressure flow control (semi-duplex)
	IEEE 802.3x flow control (full-duplex)
	Prevent the Head Of Line mechanism
	IEEE p802.1p, CoS
	Eight priorities for 4 send queue mapping 802.1p per port
	WR, SP, and FIFO queue scheduling algorithms
	Port speed limit
Reliability	UDLD (single-directional link detection protocol to prevent survival tree loop)
Reliability	Support for the Dying-Gasp functionality
Network security	The IEEE 802.1x, has a port-based access control.Support local and remote authentication, EAP end or transmission
	CHAP,EAP Certification
	Limit the maximum number of users per port
	Port protection
	News storm control
Manage configuration	Various management methods, such as CLI,Web,SNMP,TELNET.
	Software upgrades can be made through TFTP and FTP
	Local or server syslog records the system logs
	Network testing tools such as ping,traceroute
Physical dimensions	138 mm (H) 106 mm (D) 43 mm (W) (long, high and wide)
Physical dimensions	Installation: Plug and Play
Heat dissipation	For long use (24 hours), equipment heating will not cause performance decline and device deformation and damage.
Environmental requirements	Working environment: -45℃~75℃; 5%~95% without condensation
Environmental requirements	Storage environment: -45℃~80℃; 5%~95% without condensation
Power supply	Power adapter type: Switch the power adapter.
	Input rated voltage: 110V to 240V,50/60Hz.
	Input voltage fluctuation range: 20% in China; international 10%.
	Fuse: Install an unrecoverable temperature insurance (or temperature resistance) at the input end.
	Power: a maximum of 10W
