Single-mode 25G SFP28 1310nm 10KM
Single-mode 25G SFP28 1310nm 10KM

Single-mode 25G SFP28 1310nm 10KM

Model NO.
XYT-25G-QSFP-01
Quantity:
 - Specification -
Parameter


Package (Form Factor)                                                                             SFP28
Data Rate (typical)                                                                                   25.78Gb/s
Centre Wavelength                                                                                  1310nm
Distance                                                                                                   10km
Diagnostics                                                                                               Digital Monitor
Transmitter                                                                                               DFB Laser
Receiver                                                                                                    PIN photo detector
TX Output Power (dBm)                                                                           -6.5~+2
RX Sensitivity (dBm)                                                                                  -11.3
Low/High Case Temperature                                                                    0°C~70°C
Voltage Supply (typical)                                                                            3.3v
Connector                                                                                                 Duplex LC
Ordering Information
TypeRateWavelengthTransmission distanceTransitter PowerReceiver SensitivityTemperature RangeInterface
25G QSFP25Gb/s850nm100m -8.4～2.4dB≤-10.3dBmVCSELLC
1310nm10km-6.5～2dB≤-11.3dBmDFBLC

Product Features



25Gb/s serial optical interface

1310nm DFB transmitter, PIN photo-detector

2-wire interface for management specifications compliant with SFF 8472 DDM interface for optical transceivers

Operating case temperature: 0 °C to 70°C

Advanced firmware allow customer system encryption information to be stored in transceiver

Cost effective SFP28 solution, enables higher port densities and greater bandwidth

RoHS compliant

APPLICATIONS

High-speed storage area networks

Computer cluster cross-connect

Custom high-speed data pipes
