10G XFP DWDM 80KM Transceiver
10G XFP DWDM 80KM Transceiver

10G XFP DWDM 80KM Transceiver

Model NO.
10Gb/s 80km DWDM XFP Optical Transceiver
Quantity:

 - Specification -

Table 1-Optical and Electrical Characteristics

Parameter

Symbol

Min

Typical

Max

Unit

Notes

Transmitter

Centre Wavelength

λc

1260

1310

1360

nm

Spectral Width(RMS)

?λ

4

nm

Average Output Power

Pout

-9

-3

dBm

1

Extinction Ratio

ER

9

dB

Optical Rise/Fall Time(20%~80%)

tr/tf

0.26

ns

Data Input Swing Differential

VIN

400

1800

mV

2

Input Differential Impedance

ZIN

90

100

110

Ω

TX Disable

Disable

2

Vcc

V

Enable

0

0.8

V

TX Fault

Fault

2

Vcc

V

Normal

0

0.8

V

Receiver

Centre Wavelength

λc

1260

1580

nm

Receiver Sensitivity

-23

dBm

3

Receiver Overload

-3

dBm

3

LOS De-Assert

LOSD

-24

dBm

LOS Assert

LOSA

-35

dBm

LOS Hysteresis

1

4

dB

Data Output Swing Differential

Vout

400

1800

mV

4

LOS

High

2

Vcc

V

Low

0.8

V

NOTE:

1.The optical power is launched into SMF.

2.PECL input,internally AC-coupled and terminated.

3.Measured with a PRBS 27-1 test pattern@1250Mbps,BER ≤1×10-12.

4.Internally AC-coupled.

Parameters

Type

Rate

Wavelength

Transmission Distance

 Transmitter    Power

Receiver sensitivity

Interface

    Operating       temperature

CWDMXFP

10G

1270-1450nm

10KM

-1~-5

≤-14.4

LC

0-70℃

10G

1470-1610nm

40KM

-1~-3

≤-15.8

LC

0-70℃

10G

1470-1610nm

80KM

0~-4

≤-23

LC

0-70℃

DWDM    XFP

10G

C20-C60CH

40KM

-1-3

≤-15.8

LC

0-70℃

10G

C20-C60CH

80KM

0-4

≤-23

LC

0-70℃

Features
1.Up to 10Gb/s Data Link
2.Complaint to XFP MSA
3.Cooled DWDM EML laser
4.AC/AC Coupling according to MSA
5.Maximum Link Length of 80 km
6.2-Wire Interface for Integrated Digital Diagnostic Monitoring
7.Compliance with Fiber Channel FC-PI-4 800-SM-LL-L
8.XFI and Line side Loopback Mode
9.No reference clock required
10.Low Power Dissipation<3.5W
11.RoHS 6 Compliant
12.Case temperature range:-5°C to 70°C
13.Duplex LC Connector

Applications
1.Gigabit Ethernet
2.Fiber Channel
3.WDM Application
4.Switch to Switch interface
5.Switch backplane applications
6.ATM
7.SONT/SDH/PDH
8.FDDI
9.Other optical transmission system
