10G XFP 300M Optic Transceiver
10G XFP 300M Optic Transceiver

10G XFP 300M Optic Transceiver

Model NO.
10Gb/s 850nm Multimode XFP Optical Transceiver
Quantity:

 - Specification -

Table 1-Optical and Electrical Characteristics

Parameter

Symbol

Min

Typical

Max

Unit

Notes

Transmitter

Centre Wavelength

λc

1260

1310

1360

nm

Spectral Width(RMS)

?λ

4

nm

Average Output Power

Pout

-9

-3

dBm

1

Extinction Ratio

ER

9

dB

Optical Rise/Fall Time(20%~80%)

tr/tf

0.26

ns

Data Input Swing Differential

VIN

400

1800

mV

2

Input Differential Impedance

ZIN

90

100

110

Ω

TX Disable

Disable

2

Vcc

V

Enable

0

0.8

V

TX Fault

Fault

2

Vcc

V

Normal

0

0.8

V

Receiver

Centre Wavelength

λc

1260

1580

nm

Receiver Sensitivity

-23

dBm

3

Receiver Overload

-3

dBm

3

LOS De-Assert

LOSD

-24

dBm

LOS Assert

LOSA

-35

dBm

LOS Hysteresis

1

4

dB

Data Output Swing Differential

Vout

400

1800

mV

4

LOS

High

2

Vcc

V

Low

0.8

V

NOTE:

1.The optical power is launched into SMF.

2.PECL input,internally AC-coupled and terminated.

3.Measured with a PRBS 27-1 test pattern@1250Mbps,BER ≤1×10-12.

4.Internally AC-coupled.

Ordering information

Type

Rate

Wavelength

Transmission Distance

 Transmitter     Power

Receiver sensitivity

Receiver sensitivity

Operating           temperature

SFP+

10G

850nm

300M

-1~-5

≤-12

LC

0-70℃

10G

1310nm

2KM

-1~-6

≤-14.4

LC

0-70℃

10G

1310nm

10KM

-1~-6

≤-14.4

LC

0-70℃

10G

1550nm

40KM

-1~-3

≤-15.8

LC

0-70℃

10G

1550nm

80KM

0~-4

≤-23

LC

0-70℃

Features
1.Up to 10 Gb/s Data Link
2.Complaint to XFP MSA
3.Compliant with FC-Pi-4 800-M5/M6/M5E-LC-I
4.Maximum link length of 300m MMF
5.2-Wire Interface for Integrated Digital Diagnostic Monitoring
6.XFI and Line side Loopback Mode
7.No reference clock required
8.Low Power Dissipation<1.5W
9.RoHS Compliant
10.Case Temperature range ：-5°C to 70°C
11.Duplex LC Connector

Applications
1．10GBASE-ZR/ZW 10G Ethernet
2．80KM 10G Fiber Channel
3．SONET OC-192&SDH STM 64
